FXLooper

Footswitch:

• Quick press
  • If neither loops are active, activate Loop 1
  • If either loop is active by itself, toggle loops (if 1 is active, turn it off and activate 2; if 2 is active, turn it off and activate 1)
  • If in chain mode, toggle the order of the chaining
• Long Press (1 second)
  • If no loops are active, enable chain mode; starts with Send1 chained into Send2
  • If anything is active, disable loops

MIDI Commands:

PC10 – No loops Active

PC11 – Loop 1 active

PC12 – Loop 2 active

PC20 – Toggle between active loops (if 1 is active, turn it off and activate 2; if 2 is active, turn it off and activate 1); If in Chain mode, switch the chain order

PC31 – Chain: Activate both loops, FX1 into FX2; Input -> FX1 -> FX2 -> Output

PC32 – Chain: Activate both loops, FX2 into FX1; Input -> FX2 -> FX1 -> Output

To change the MIDI Channel:

When the unit boots, it will test all 3 lights, turn them off, then flash the MIDI channel.  Each Green flash is +5, each Red flash is +1. Add them up, and that's the MIDI channel. By default, it's on Channel 4.

To change the channel, first send PC125, then send PC(1-16) to set the MIDI channel to that channel. The unit will reboot to the new MIDI channel.

PC>16 will exit MIDI channel change mode

To set the default boot mode:

First send PC126, then:

PC0 – All loops off on boot

PC1 – Loop1 active on boot

PC2 – Loop2 active on boot

PC3 – Loop 1 into Loop 2, active on boot

PC4 – Loop2 into Loop 1, active on boot

PC > 4 – Exit default boot edit mode

The unit will reboot to the new default mode if you sent pc0-4.
